Honey Wax Separator Machine
Description of Honey Wax Separator Machine
Press the starting switch: turn the converter knob to start the motor, observe whether the screw is turning in the correct direction (clockwise), shall not be reversed.
The seal wax cut from the nest frame is continuously put into the hopper, and the seal wax is transported from the lower hopper to the tail end of the screw by dragging the screw through the motor reducer.In the course of transportation, the seal wax can be separated from beeswax by the change of screw bottom diameter and pitch, and a certain pressure will be produced in the screw cylinder to separate honey from beeswax.The beeswax is transported to the tail of the screw in the screw groove with the rotation of the screw, and the excluded beeswax is discharged into the wax receiving tank. Honey flows through the overflow holes on the wall of screw chamber and flows into the honeycomb tank below screw chamber.
Parameters of Honey Wax Separator Machine
| Product Name | Screw type honey wax separator |
| Shape Size | 1100*450*900cm |
| Packing Size | 1420*560*860cm |
| Motor reducer type | KA F47-NA14-1 .1(1.5) Kw-A |
| Voltage | 380(single phase 220) V |
| Screw speed | 9-14r / min |
| Screw diameter | φ 125(φ 150 φ 180) mm |
| Extrusion | 50(100,150) Kg/h |
| Weight | 90Kg |
Service of Honey Wax Separator Machine
About sample:It will be sent within 7 working days after receiving your advance payment.
Best pre-sale service:We are a 14-year beekeeping equipment manufacturer with 30 years of beekeeping industry experience.Located in the largest bee machinery production base in China,Changge.Focus on R&D and production of honey extractor.Multi-sweet’s products have been exported to all over the world and won great feedback,gradually become a leader in the beekeeping industry.
Best after-sale service: Any damage caused by the product itself belongs to our compensation.
